SCXA-60 Water Slot Router Machine
Time:2019/01/04
Classify:Upvc Window and Door Processing Machine

PRODUCT

Looking forward to build future with you and common development.

  • Feature


     Milling all kinds of water slots and air pressure balance groove.

     Full design with high rigidity, processing beautiful water slot, high appearance quality.

     Automatic cutter changer, one time clamp to finish water slots processing.

     Special feeding system results no maintenance and high milling quality.

     Easily adjustment for the cutter location to meet different kinds of profiles.

     Adopt linear bearing motion to ensure the processing precision.

     This three-axis water slot router can achieve the function of four-axis water slot router.



    Technical Parameter:


    Model

    SCXA-60

    Input voltage

    220V 50Hz

    Input power

    1.2 kw

    Air pressure

    0.5~0.8MPa

    Air consumption

    30L/min

    Motor rotating speed

    28000r/min

    Max. milling length

    100mm

    Max. milling depth

    30mm

    Diameter of milling cutter

    φ4mmφ5mm

    Overall dimension

    1200×1200×1800mm
