LXSJ6A-250 Tenon Milling Machine

PRODUCT

Looking forward to build future with you and common development.

  • Feature


    ◎ It is promoted according to international and domestic curtain wall market.

    ◎ Six sets of cutting tools can be combined freely to any size according to customer’s requirement, and two sets of them can be adjusted in the range of 180°.

    ◎ It's a new type of curtain wall processing machine and applys to various kinds of profiles. It is of wide range processing, easy operation and high efficient to meet customers’ demand.

    ◎ The machine can complete profile fixed, tools moving and longer profile shaped and finished many times and large quantity.



    Technical Parameter


    Model

    LXSJ6A-250

    Input voltage

    380V 50Hz

    Input power

    14.5kw

    Air pressure

    0.5~0.8MPa

    Air consumption

    150L/min

    Motor rotation speed

    2800r/min

    Cutting tool range

    1650mm

    Worktable size

    510×480mm

    Milling cutter diameter

    φ250mm

    Adjustment range

    X:80mm Y:280mm

    Overall dimension

    4810×1340×1965mm
