Looking forward to build future with you and common development.
Feature
◎ Used for cutting profiles such as aluminum and pvc profile and curtain wall.
◎ Two heads cutting angle 90°, 45° are available. The system can store various of profiles, convenience and efficiency.
◎ Swing arm type feeding results the gold cutting angle for the saw and profile, more stable, durable, smooth, and accuracy.
◎ It has the features of high accuracy, adjustable, easy operation and has the international first-class Level.
Technical Parameter:
Model
LJZ2-500×4500
Input voltage
380V 50Hz
Input power
4.5Kw
Air pressure
0.5~0.8MPa
Air consumption
200L/min
Spindle speed
3200r/min
Cutting length
430~4500mm
Cutting width
10~240mm
Cutting height
10~140mm
Cutting angle
90° 45°
Saw feeding speed
0~3m/min
Saw blade standard
φ500×4.4×φ30×Z120
Overall dimension
5400×1300×1450mm
