LJZ2-500×4200(5000) Double Mitre Saw
Time:2018/12/29
Classify:Aluminum Windows and Curtain Wall Processing Machine

PRODUCT

Looking forward to build future with you and common development.

  • Feature


    ◎ Two heads work independently or together.

    ◎ Uniform speed feeding and smooth motion due to air-draulic damping cylinder.

    ◎ Saw blade feeding system adopts imported linear guide pair, with high accuracy and smooth working.

    ◎ Automatic protecting guards result convenience and safety.

    Technical Parameter:


    Model

    LJZ2-500×4200(5000)

    Input voltage

    380V 50Hz

    Input power

    4.5Kw

    Air pressure

    0.5~0.8MPa

    Air consumption

    200L/min

    Spindle speed

    3200r/min

    Cutting length

    360~4200mm(360~5000mm)

    Cutting width

    10~130mm

    Cutting height

    10~300mm

    Cutting angle

    90° 45° 67.5°

    Saw feeding speed

    0~3m/min

    Saw blade standard

    φ500×4.4×φ30×Z120

    Overall dimension

    5500(6300)×1700×1600mm
