Looking forward to build future with you and common development.
Feature
◎ Apply to aluminum and PVC profiles for 45 degree cutting.
◎ Imported linear bearing guide results in highly precise processing.
◎ Super big worktable enables to cut several profiles in one time.
◎ Two heads can work independently or together.
◎ Working with a single head mitre saw, highly improves the efficiency.
Technical Parameter:
Model
LJZ2-450×4200
Input voltage
380V 50Hz
Input power
3.0Kw
Air pressure
0.5~0.8MPa
Air consumption
220L/min
Spindle speed
3200r/min
Cutting length
310~4200mm
Cutting width
10~320mm
Cutting height
10~100mm
Cutting angle
45°
Saw feeding speed
0~3m/min
Saw blade standard
φ450×4×φ30×Z120
Overall dimension
5500×1900×1600mm
