LJK-500 Notching Saw

PRODUCT

Looking forward to build future with you and common development.

  • Feature


    ◎ It is apply to cutting the angles on aluminum profiles for curtain wall and skylight roof.

    ◎ The two saws works together can cutting the special angles.

    ◎ It adopts magnetic railing ruler, easy to see the cutting angle and work table height.

    ◎ The two saw blades can be swing on the range +45°/-45°.

    ◎ The electrical system installs protector and open door breaker to guarantee the safety.



    Technical Parameter


    Model

    LJK-500

    Input voltage

    380V 50Hz

    Input power

    2×2.2kw

    Air pressure

    0.5~0.8MPa

    Air consumption

    60L/min

    Motor rotation speed

    2800r/min

    Cutting depth

    150mm

    Milling cutter diameter

    φ500×4.4×φ30×Z120

    Overall dimension

    3140×1380×1800mm

  • 20181218133156536.jpg
